Manual reset, open on rise (normally closed)
Single pole, single throw (SPST)
Triple-function: Auto cutoff, manual cutoff & reset
Specifications
Operating temperature range: 0～150℃ (32～302°F)
Auto reset temp. Below zero degree; manually reset-table temp. is required below 30℃ from operating temp.
Temperature tolerance: ±3.0K, ±5.0K, ±8.0K, ±10.0K
Contact resistance: 50mΩor less
Electrical Rating:
Applications
Electrical rating | Agency approvals | |||||
VDE | UL | TÚV | CQC | Life cycles | Remarks | |
AC125V/10A | ● | 6 K | Phenolic | |||
AC125V/16A | ● | 6 K | ||||
AC250V/10A | ● | ● | ● | 10 K | ||
AC250V/16A | ● | ● | ● | 10 K | ||
